| Pilot projects | Test conditions | Target |
| Optical index | Insertion loss | 1310nm LED | ＜0.3? (typical:0.1) |
| Echo Loss | 1310nm LD | PC≥45，UPC＞50，APC＞60 |
| Environmental Performance Test
(Maximum variation of insertion loss) | High temperature | +85oC, 168 hours | 0.2 |
| Temperature Cycle | -40?oC～+75oC,21cycles, 168 hours | 0.2 |
| Wet heat (steady state) | 75oC, 95%R.H, 168 hours | 0.2 |
| Hygrothermal cycle | -10?oC～+65oC, 95%R.H. ,
21 cycles, 168 hours | 0.2 |
| Mechanical Performance Test
(Maximum variation of insertion loss) | Vibration | 10 Hz～55Hz, 1.5mm(p-p) | 0.1 |
| Bend | 0.9kgf, -90°～+90° 100 cycles | 0.1 |
| Reverse | 2.5kgf, 10 times/min,±180°,???200 times | 0.1 |
| Tensile | 90N，10min | 0.1 |
| Drop | 1.5 m?High , 8 times | 0.2 |
| Repeatability | 10 times | 0.1 |
| Durability | >500 times | 0.2 |
